Electrical insulation tape 19 mm x 20 m x 0.15 mm yellow/green. white. blue. red. black (x 10)

Electrical insulation, protection and identification.
General use.
Plasticized PVC tapes, synthetic rubber adhesive mass.
Pressure-sensitive flexible tape.
Flame-retardant.
Acid and alkali resistant.
Lead free.

Colour
  • Yellow/green; white; blue; red; black
  • Black
  • Blue
  • Red
  • White
  • Yellow
  • Green
  • Yellow/green
Length (m)
  • 20
Width (mm)
  • 19
Thickness (mm)
  • 0.15
Quantity
  • 10
  • 8
Specifications Tech

Dimensions: 19 mm x 20 m x 0.15 mm.
Tensile strength: > 28 N/cm.
Elongation at break: > 200 %.
Adhesion to steel 2B: 2.2 N/cm.
Adhesion to backing: 2.0 N/cm.
Dielectric strength: 45 kV/mm.
Insulation resistance: 1011 Ω/25 mm.
Operating temperature: 0 °C to +90 °C.

Uses & advantages Info

When making cable looms, apply the product over a minimum of 50 % of the surface.


Apply the product at a temperature between -10 °C and +40 °C.
